Epson EB-S04
- High-quality, bright images: 3LCD technology and equally high White and Colour Light Output
- Contrast ratio of 15,000:1: Deep, rich blacks and dense shadow areas
- Enjoy the big screen experience: Screen size of up to 300 inches
- 15 years of your favourite content{s1: Lamp and filter life of 10,000 hours
- Versatile and flexible control: Project from a range of sources with HDMI and mobile connectivity
| SKU | V11H716041 |
|---|---|
| EAN | 5054629905197 |
| Manufacturer | Epson |
| Availability | No |

Enjoy the big screen experience at home
Create a spectacular cinema-style occasion for friends and family and enjoy high-quality images on a huge screen up to 300+ inches1. Films, sporting events and once-in-a-lifetime spectacles will all appear sharp and clear thanks to a high Colour Light Output (CLO), meaning colours are bright and vivid, even in brightly-lit rooms or outdoors. In fact, Epson projectors are up to three times brighter than competitor 1-chip DLP projectors2. With a wide range of options available, Epson is sure to have the right projector to deliver the ultimate viewing experience.
1Selected models only
2Colour Brightness (Color Light Output) measured in accordance with IDMS 15.4. Colour Brightness will vary depending on usage conditions. Leading Epson 3LCD business and education projectors compared to leading one-chip DLP projectors, based on NPD data for June 2013 through May 2014 and PMA Research data for Q1 through Q3 2013.

Pick out the finest detail and bring content to life
Everyone wants to be able to view high-quality videos and images with striking colours that look great in a range of ambient lighting conditions. Thanks to a 15,000:1 contrast ratio1, projections will have crisp, clear blacks with clearly defined shadows that look great, even in brightly-lit rooms.
1Selected models only
The whole family will enjoy this high-quality, versatile projector. Whether watching films and family photos on a big screen or delivering crisp, clear presentations, the stylishly-designed EB-S04 is ideally suited for both the home and office. Easy to move and quick to set-up, users can start watching exceptional-quality content in no time at all.
15 years worth of entertainment
With a long lamp and filter life, even if using the projector to watch a movie every day, it would be up to 15 years before either would need to be changed{s1.
High-quality, bright images
Experience exceptional-quality images that are three times brighter than competitor products{s2 thanks to 3LCD technology and equally high White and Colour Light Output. View your content like never before and pick out even the finest detail with crisp, clear blacks creating clearly defined shadows, all thanks to a 15,000:1 contrast ratio.
The big picture
Able to take content from a range of sources and display it up to a massive 300 inches, the EB-S04 uses an HDMI inputs to allow users to broadcast high-quality digital video and audio content. You can even project photos and documents straight from a smartphone or tablet with Epson's iProjection app{s3.
Everything included for fuss-free installation
An included carry case makes for easy movement of the projector from room to room. Horizontal and vertical keystone correction mean the projector can be installed in a number of places without distorting the image.
Eco-friendly features
By varying the lamp power according to what content is being displayed, the EB-S04 can help save energy, while eco-mode helps reduce power consumption and extend lamp life.
| Projector | |
|---|---|
| Number of colours | 1.073 billion colours |
| White light output | 3000 ANSI lumens |
| Colour light output | 3000 ANSI lumens |
| Projector native resolution | SVGA (800x600) |
| Projection distance (wide) | 1.77 - 1.77 m |
| Projection distance (tele) | 2.4 - 2.4 m |
| Native aspect ratio | 4:3 |
| Supported aspect ratios | 4:3 |
| Screen size compatibility | 762 - 8890 mm (30 - 350") |
| Projection distance | 1.77 - 2.4 m |
| Contrast ratio (dynamic) | 15000:1 |
| Zoom ratio | 1.35:1 |
| Projector brightness (economic mode) | 2100 ANSI lumens |
| Matrix size | 1.4 cm (0.55") |
| Keystone correction, vertical | -30 - 30° |
| Keystone correction, horizontal | -30 - 30° |
| Projection technology | 3LCD |
| Projector brightness | 3000 ANSI lumens |
| Lamps | |
| Lamps quantity | 1 lamp(s) |
| Lamp power | 200 W |
| Light source type | Lamp |
| Service life of light source | 5000 h |
| Service life of light source (economic mode) | 10000 h |
| Light source | |
| Lamps quantity | 1 lamp(s) |
| Lamp power | 200 W |
| Light source type | Lamp |
| Service life of light source | 5000 h |
| Service life of light source (economic mode) | 10000 h |
| Lens system | |
| Zoom ratio | 1.35:1 |
| Focus | Manual |
| Focal length range | 16.7 - 16.7 mm |
| Aperture range (F-F) | 1.44 - 1.44 |
| Offset | 8% |
| Video | |
| Video processing | 10 bit |
| Video colour modes | Blackboard, Cinema, Dynamic, Presentation, sRGB |
| Full HD | No |
| HD-Ready | No |
| 3D | No |
| Audio | |
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 1 |
| RMS rated power | 1 W |
| Ports & interfaces | |
| DC-in jack | Yes |
| VGA (D-Sub) ports quantity | 1 |
| HDMI ports quantity | 1 |
| USB 2.0 ports quantity | 2 |
| USB connector type | USB Type-A, USB Type-B |
| Composite video in | 1 |
| Audio (L/R) in | 1 |
| S-Video inputs quantity | 1 |
| Network | |
| Ethernet LAN | No |
| Wi-Fi | No |
| Sound emission | |
| Noise level | 37 dB |
| Noise level (economic mode) | 28 dB |
| Technical details | |
| DC-in jack | Yes |
| Product colour | Black, White |
| Lamp power | 200 W |
| Products per pallet | 78 pc(s) |
| Quantity per pack | 1 pc(s) |
| Pallet gross width | 80 cm |
| Pallet gross length | 120 cm |
| Pallet gross height | 119 cm |
| Products per pallet layer (UK) | 6 pc(s) |
| Products per pallet layer | 6 pc(s) |
| Products per pallet (UK) | 78 pc(s) |
| Pallet width (UK) | 100 cm |
| Pallet length (UK) | 120 cm |
| Pallet height (UK) | 119 cm |
| Performance | |
| Noise level | 37 dB |
| Noise level (economic mode) | 28 dB |
| Features | |
| Noise level | 37 dB |
| Noise level (economic mode) | 28 dB |
| Country of origin | Philippines |
| Multimedia | |
|---|---|
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 1 |
| RMS rated power | 1 W |
| Design | |
| Product type | Standard throw projector |
| Cable lock slot type | Kensington |
| Product colour | Black, White |
| LED indicators | Yes |
| Cable lock slot | Yes |
| Placement | Desktop |
| Display | |
| Built-in display | No |
| Power | |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power source | AC |
| Power consumption (typical) | 277 W |
| Power consumption (standby) | 0.26 W |
| Power consumption (economy mode) | 207 W |
| Packaging data | |
| Package width | 350 mm |
| Package depth | 360 mm |
| Package height | 160 mm |
| Package weight | 3.83 kg |
| Security | |
| Cable lock slot type | Kensington |
| Cable lock slot | Yes |
| Indication | |
| LED indicators | Yes |
| Operational conditions | |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage temperature (T-T) | -10 - 60 °C |
| Storage relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 5 - 35 °C |
| Weight & dimensions | |
| Package width | 350 mm |
| Package depth | 360 mm |
| Package height | 160 mm |
| Weight | 2.4 kg |
| Width | 297 mm |
| Depth | 234 mm |
| Height | 77 mm |
| Package weight | 3.83 kg |
| Packaging content | |
| Remote control included | Yes |
| Warranty card | Yes |
| Manual | Yes |
| Carrying case | Yes |
| Batteries included | Yes |
| AC adapter included | Yes |
| Logistics data | |
| Products per pallet | 78 pc(s) |
| Quantity per pack | 1 pc(s) |
| Pallet gross width | 80 cm |
| Pallet gross length | 120 cm |
| Pallet gross height | 119 cm |
| Products per pallet layer (UK) | 6 pc(s) |
| Products per pallet layer | 6 pc(s) |
| Products per pallet (UK) | 78 pc(s) |
| Pallet width (UK) | 100 cm |
| Pallet length (UK) | 120 cm |
| Pallet height (UK) | 119 cm |
| Other features | |
| Power consumption (economy mode) | 207 W |
